The Boss Hi-fi System
Technical specifications
The Record Player
The Amplifier
The Speakers
| Motor: | |
| Drive: | Belt Drive |
| Speed: | 33/45/78 |
| Wow & Flutter: | < ±0,1 % (DIN WTD) |
| Tonearm: | |
| Auto-Start/Stop Function: | Manual Operation |
| Bearing: | Ball-bearing |
| Effective Length: | 221.5mm |
| Type: | Statically Balanced |
| Cartridge Weight Range: | 5g to 9g |
| Factory-Fitted Cartridge: | Ortofon 2M Red |
| Platter: | |
| Material: | Aluminium die-cast |
| Mat: | Rubber 2.5mm |
| Diameter: | 305mm |
| Weight: | 850g |
| Plinth: | |
| Material: | MDF, folded |
| Surface Finish: | Black wood |
| Connections: | RCA socket |
| Dimensions (HxWxD): | 435 x 367 x 145mm (Dustcover closed) |
| Weight: | 5.8kg |
| Power plug: | External Power Supply |
| Rated Power Output | 2 x 50 Watts RMS (8 Ohms, THD<1%); 2 x 75 Watts RMS (4 Ohms, THD<1%) |
| Frequency Response | 20Hz - 20kHz (+/- 0.3dB) |
| Signal To Noise Ratio | >109dB (A-weighted); > 79dB (Phono MM, A-weighted) |
| Total Harmonic Distortion (THD) | <0.0004% (1kHz @2V, Volume = 0dB) |
| Analogue Inputs | 3 x AUX, 1 x Power Amplifier, 1 x Phono (MM) |
| Digital Inputs | 2 x SPDIF (Coax), 2 x SPDIF (Optical), 1 x HDMI ARC, 1 x Bluetooth (aptX / aptX HD) |
| Audio Outputs | 1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger |
| Included Accessories | Remote Control |
| Dimensions (H x W x D) | 65 x 444 x 299mm |
| Weight | 7.78kg |
| Colour Choice | Black or Silver |
| General description | 2-way bookshelf speaker |
| Bass driver | 6.5"(150mm) advanced PP Cone |
| Treble driver | 1"(25mm) Textile Dome |
| Recommended amplifier power | 20-120W |
| Nominal impedance | 8Ω Compatible |
| Sensitivity (2.83V @ 1m) | 88dB |
| Frequency response (+/-3dB) | 50Hz ~ 20kHz |
| Dimensions ( H x W x D ) | 335 x 200 x (285+28) mm |
| Net weight | 8.2kg/pcs |
